| Fiber Type | OS2 Singlemode Fiber (9/125μm), SC/APC to FC/APC Simplex Fiber Patch Cable |
| Fiber Standard | ITU-T G.657.A1 Bend Insensitive Fiber |
| Connector Types | SC APC Simplex (8° Angled Physical Contact) to FC APC Simplex (8° Angled Physical Contact) |
| Connector Ferrule Material | High-Precision Zirconia Ceramic |
| Insertion Loss | ≤ 0.3 dB (Typical) |
| Return Loss | ≥ 60 dB |
| Mating Durability | Up to 1000 Mating Cycles |
| Cable Jacket Material | Flame-Retardant Riser (OFNR) |
| Cable Diameter | 2.0 mm Tight-Buffered Yellow Jacket |
| Minimum Bend Radius | 10 mm |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Transmission Wavelengths | 1310 nm, 1490 nm, 1550 nm |
| Maximum Transmission Distance | Up to 10 km at 1310 nm, up to 40 km at 1550 nm |
| Standards Compliance | IEC 61754, Telcordia GR-326, RoHS Compliant |
| Cable Length Options | Custom Lengths Available |
| Applications | Telecom Networks, Data Centers, CATV, DWDM Systems, Optical Communications |
| Color Coding | Yellow Jacket for Singlemode Fiber Identification |
| Packaging | Individually Packaged with Protective Dust Caps |
SC/APC to FC/APC Simplex Fiber Patch Cable, Single Mode, 9/125, 2.0mm, Custom Length
- Premium OS2 Singlemode Fiber (9/125μm) – Capable of high speed data transmission up to 400G and long distances of up to 10km on 1310nm and 40km on 1550nm.
- Low Insertion Loss (≤0.3dB) – Optical signal transmission with minimal loss or degradation.
- High Return Loss (≥60dB) – 8° angled polished APC connectors that significantly reduce back reflection, therefore conserving signal integrity.
- Durable Precision Zirconia Ferrule Connectors – Making stable connections that are resistant to vibration, excellent alignment, and function after upwards of 1000 mating cycles.
- Bend-Insensitive Fiber (G.657.A1) – Allowing tight bending with a minimum bend radius of 10mm, reducing attenuation in tight spaces and installations.
- Flame-Retardant Riser (OFNR) Jacket – Riser rated to ensure safe installations from floor to floor with the yellow tight-buffered 2.0mm cable.
- Simplex SC APC to FC APC – Configuration is for unidirectional data transmission and supports telecom, data center, CATV, and DWDM.
- Compliant with industry standards – meets IEC 61754 and Telcordia GR-326.
- Custom lengths available – Length can be determined based on a specific application for flexibility.
- Protective dust caps on connectors – Each connector is protected with dust caps when being stored or handled to maintain cleanliness.
