| Product Name | LC/SC/FC/ST/LSH Armored Anti-Rodent Fiber Optic Pigtail |
| Fiber Type | OS2 Single Mode (G.652D) |
| Fiber Count | 2 to 48 fibers, customizable |
| Connector Types | LC, SC, FC, ST, LSH |
| Cable Diameter | Single core: 2.0 mm; Dual core: 3.0 mm |
| Insertion Loss | ≤ 0.3 dB |
| Return Loss | ≥ 50 dB |
| Ferrule Material | Ceramic |
| Cable Jacket Material | High quality PVC |
| Armoring | Stainless steel tubular wire coil for protection against rodent bites and mechanical damage |
| Operating Temperature Range | -20°C to +85°C |
| Mechanical Durability | ≥ 500 mechanical cycles; ≥ 1000 connector mating cycles |
| Tensile Strength | High tensile strength due to armored design |
| Flame Retardant Rating | Riser (OFCR) Or LSZH optional |
| Cable Construction | Tight-buffered fiber with aramid yarn strength member |
| Polishing Type | UPC or APC available |
| Compatibility | Compatible with routers, switches, fiber distribution frames, optical transceivers, etc. |
| Applications | Fiber optic communication rooms, LAN data transmission, FTTH, security monitoring |
| Customization Options | Fiber count, cable length, connector type, jacket material, polish type |
| Additional Features | Hot swappable connectors, low insertion loss after repeated mating, serialized for traceability |
LC/SC/FC/ST/LSH Armored Anti-Rodent Fiber Optic Pigtail, Customized 2-48 Fibers OS2 Single Mode
- Armored Anti-Rodent Protection: The armored protection is created to safeguard against rodent bites, crushing, and mechanical damage, and to ensure durability in harsh environments by including a tubular stainless steel wire coil.
- High Quality OS2 Single Mode Fiber: The use of high-quality OS2 fiber cores from FiberHome ensures low attenuation, stable data transmission and low signal loss.
- Various Connector Options: Available with LC, SC, FC, ST and LSH connectors for application in different devices such as routers, switches, fiber distribution frames and optical transceivers.
- Low Insertion Loss & High Return Loss: Equipped with ceramic ferrules polished to a tolerance of ≤0.3dB insertion loss and ≥50dB of return loss.
- Strong Outer Jacket: Made of strengthened, high grade PVC that is smooth, mechanically flexible and free from corrosion, allowing for tensile strength and protection from environmental damage.
- Customizable Fiber Count & Length: Clear accommodations for 2 to 48 fiber options with any customized cable length.
- Durable Mechanical Performance: Accurate accommodation for use with over 500 mechanical durability cycles and over 1000 connector mating events.
- Wide Application Range: Ideal for use in fiber optic communication rooms, local area network data transmission, security monitoring and other fiber to the home installations.
- Hot Swap Feature: Allows for easy plug-and-play installation while maintaining low insertion loss over the series of connections made.
