| Product Type | Fiber Optic Attenuator FC-FC Type Female to Female |
| Attenuation Range | 0.5 dB to 30 dB, adjustable |
| Insertion Loss | ≤ 0.2 dB |
| Return Loss | > 50 dB |
| Repeatability | ≤ 0.10 dB |
| Interchangeability | ≤ 0.20 dB |
| Connector Type | FC-FC / UPC Female to Female |
| Ferrule Material | Ceramic sleeve (also available with metal sleeve) |
| Applicable Fiber Type | Single-mode and multimode compatible |
| Operating Wavelength | 1260 nm to 1620 nm |
| Operating Temperature | -40°C to +80°C |
| Storage Temperature | -40°C to +80°C |
| Durability (Mating Cycles) | > 1000 cycles |
| Vibration Resistance | Amplitude 1.52 mm, frequency 10 Hz to 55 Hz |
| Environmental Compliance | RoHS compliant |
| Protection Features | Dust caps included; flame retardant; vibration and shock resistant |
| Application Areas | Fiber optic communication rooms, broadband access, LANs, ODF distribution frames, fiber optic instruments |
Adjustable Fiber Optic Attenuator FC-FC Type 0.5-30dB Female to Female Flange Coupling Adapte
- Broad Attenuation Range: Adjustable from 0.5 dB to 30 dB while also providing precise control of optical signal strength.
- Low Insertion Loss: Typical insertion loss around 0.2 dB, resulting in very little signal degradation.
- High Stability: Repeatability is ≤0.10 dB; interchangeability is ≤0.20 dB.
- Reliable Ceramic Ferrule: Superior ceramic sleeve providing uniform light transmission and accuracy of attenuation.
- Rugged: Designed for temperature ranges of -40°C to +80°C and can withstand vibration levels.
- Good Compatibility: Female-to-female FC/UPC connectors allow for reliable, flame-retardant, plug-and-play optical compatibility.
- Excellent Isolation: Suppression of ground loop noise and external interference provides clean signal transmission.
- Long Life: Supports >1000 mating cycles without degradation in performance.
- Lightweight & Portable: Integrates well with equipped dust covers for easy transport and care.
- Unique Application: Suitable for any fiber optic communication room, broadband access, LANs, ODF distribution frames and fiber optic instruments.
