25G SFP28 Module 1310nm/1490nm/1550nm Compatible with Cisco Mikrotik HPE TP-LINK HP Juniper

Transmission Distance: 100m | 2km | 10km | 20km | 30km | 40km | 50km
Compatible Brands: Arista | Avago | Brocade | Chelsio | Ciena | Cisco | Dell | D-Link | Extreme | Fortinet | Generic | H3C | Huawei | IBM | Juniper | Intel | Mellanox | Mikrotik | Ubiquiti | ZTE | Other
Wavelengths: 1310nm | 1490nm | 1550nm

Compliant: MSA form factor, ISO 802.3by/802.3cc compliant, fully compliant with DDM/DOM for real-time monitoring.
Moveable: Supports plug-and-play deployment with IEEE-compliant optical 25G interfaces when link specifications are shared.
Tested Performance: Each unit is port-tested to verify link performance, BER, DOM, and thermal performance.
Support: Free 30-day return, 5-year warranty, lifetime technical support.

Original price was: $109.00.Current price is: $74.00.

Categories: Fiber Optic Transceivers, 10G/25G/40G/100G Modules

Description

25G SFP28 Transceiver Module is intended for 25GBASE Ethernet interconnections and has been extensively laboratory tested on switches, routers, servers, and NICs for compatibility and performance. The module is RoHS compliant and is designed and tested for use in data center applications as well as Fibre Channel.

Specifications

Part No.	Data Rate	Wavelength	Distance	Optical Engine	TX Power (dBm)	RX Sensitivity (dBm)	Connector	Voltage
BYXGD-SFP28-25G-850-100M	25G	850 nm	100 m	VCSEL/PIN	2.4 ~ -8.4	< -10	LC	3.3 V
BYXGD-SFP28-25G-850-400M	25G	850 nm	400 m	VCSEL/PIN	3 ~ -5	< -10	LC	3.3 V
BYXGD-SFP28-25G-1310-300M	25G	1310 nm	300 m	DFB/PIN	2 ~ -4.5	< -10.5	LC	3.3 V
BYXGD-SFP28-25G-1310-10KM	25G	1310 nm	10 km	DFB/PIN	-5 ~ 5	< -11.5	LC	3.3 V
BYXGD-SFP28-25G-1310-20KM	25G	1310 nm	20 km	DFB/PIN	-5 ~ 5	< -12	LC	3.3 V
BYXGD-SFP28-25G-CWDM-10KM-1271-1371	25G	1271–1371 nm	10 km	CWDM DFB/PIN	7 ~ 0	< -14	LC	3.3 V
BYXGD-SFP28-25G-CWDM-40KM-1271-1331	25G	1271–1331 nm	40 km	CWDM DFB/APD	7 ~ 0	< -19	LC	3.3 V
BYXGD-SFP28-25G-CWDM-20KM-1351-1371	25G	1351–1371 nm	20 km	CWDM DFB/APD	7 ~ 0	< -19	LC	3.3 V
BYXGD-SFP28-25G-DWDM-10KM-D18-D61	25G	DWDM D18–D61	10 km	EML/PIN	6 ~ -3	< -14.5	LC	3.3 V
BYXGD-SFP28-25G-DWDM-15KM-D18-D61	25G	DWDM D18–D61	15 km	EML/APD	6 ~ -3	< -19	LC	3.3 V
BYXGD-SFP28-25G-1310-30KM	25G	1310 nm	30 km	DFB/APD	4 ~ -2	< -19	LC	3.3 V
BYXGD-SFP28-25G-1310-40KM	25G	1310 nm	40 km	DFB/APD	6 ~ 0	< -19	LC	3.3 V
BYXGD-SFP28-25G-1310-60KM	25G	1310 nm	60 km	DFB/APD	6 ~ 0	< -20	LC	3.3 V
BYXGD-SFP28-25G-BIDI-10KM-T1270-R1330	25G	Tx 1270 / Rx 1330 nm	10 km	DFB/PIN	4 ~ -4	< -11	LC	3.3 V
BYXGD-SFP28-25G-BIDI-10KM-T1330-R1270	25G	Tx 1330 / Rx 1270 nm	10 km	DFB/PIN	4 ~ -4	< -11	LC	3.3 V
BYXGD-SFP28-25G-BIDI-20KM-T1270-R1330	25G	Tx 1270 / Rx 1330 nm	20 km	DFB/PIN	-2 ~ 4	< -12	LC	3.3 V
BYXGD-SFP28-25G-BIDI-20KM-T1330-R1270	25G	Tx 1330 / Rx 1270 nm	20 km	DFB/PIN	-2 ~ 4	< -12	LC	3.3 V
BYXGD-SFP28-25G-BIDI-40KM-T1270-R1330	25G	Tx 1270 / Rx 1330 nm	40 km	DFB/APD	6 ~ 0	< -18	LC	3.3 V
BYXGD-SFP28-25G-BIDI-40KM-T1330-R1270	25G	Tx 1330 / Rx 1270 nm	40 km	DFB/APD	6 ~ 0	< -18	LC	3.3 V
BYXGD-SFP28-25G-BIDI-50KM-T1270-R1310	25G	Tx 1270 / Rx 1310 nm	50 km	DFB/APD	6 ~ 0	< -19	LC	3.3 V
BYXGD-SFP28-25G-BIDI-50KM-T1310-R1270	25G	Tx 1310 / Rx 1270 nm	50 km	DFB/APD	6 ~ 0	< -19	LC	3.3 V
