Cisco XFP-10G-BX60D-I Compatible 10GBASE-BX BiDi XFP Transceiver has been developed for long-distance 10G links requiring high optical sensitivity and stable performance. Its DFB transmitter and APD receiver provide performance enhancement for weak return signals, making it appropriate for 60km backbone, metro aggregation, and carrier access applications.
Constructed with a rugged metal housing for better EMI resistance, the module is capable of consistent operation across a variety of routing and switching platforms. Full compatibility testing has been performed with Cisco XFP-10G-BX60D-I, Juniper EX-XFP-10GE-BX32-60, Dell GP-XFP-10GBX-D-60, and Brocade 10G-XFP-BXD-60K to allow for multi-vendor interoperability. Each transceiver is tested for optical performance and data integrity on an individual basis to provide reliable long-distance performance while enabling service providers, enterprises, and metro network operators to maximize the use of their BiDi fiber.
Specifications
| Parameter | Value |
| Model | BYXGD XFP-10G-BX60D-I |
| Form Factor | XFP |
| Max Data Rate | 10.7 Gbps |
| Wavelength | 1330 nm TX / 1270 nm RX (BiDi) |
| Optical Components | DFB laser transmitter / APD receiver |
| Connector | LC simplex (UPC) |
| Fiber Type | OS2 single-mode fiber |
| Max Link Distance | 60 km |
| DDM/DOM | Supported via 2-wire interface |
| Transmit Optical Power (TX) | 1 to 5 dBm |
| Receiver Sensitivity (RX) | ≤ -21 dBm to ≤ -23 dBm (BiDi long-reach) |
| Power Consumption | < 1.5 W |
| Supply Voltage | +3.3 V |
| Operating Temperature | 0 to 70 °C (32 to 158 °F) |
| Management Interface | I2C per XFP MSA |
| Compliance (MSA) | XFP MSA INF-8077i Rev. 4.5 |
| Compliance (Ethernet) | IEEE 802.3ae 10 Gigabit Ethernet |
| Applications | 10GBASE-BX, SONET/SDH OC-192/STM-64 as defined by MSA standards |
| EMI/Safety | Meets XFP MSA EMI and laser safety requirements |
| Warranty | 5 Years |
