0.9mm GJFJV Tight Buffer Fiber Optic Cable – Single-Fiber Indoor, LSZH/PVC Jacket, Aramid Strength Member

0.9mm Tight Buffered Fiber: Provides ease of stripping and accuracy of termination; designed for use indoors.
Aramid Yarn Strength Member: Provides excellent tensile strength and mechanical protection and protects the cable during installation and operation.
LSZH or PVC Outer Jacket: Flame retardant and has low smoke emission properties which enhance safety in indoor confined spaces.
Low Attenuation: Optical loss is 0.34 dB/km at 1310 nm and 0.20 dB/km at 1550 nm for quality signals.
Compact and Lightweight Design: Slim cable diameter for installation in tight spaces and reduces overall bulk of cable.
Good Flexibility: Allows the cable to be routed and handled without adversely affecting the fibers.
Moisture and Corrosion Resistant: Outer jacket allows for environmental factors that contribute to the lifetime of the cable indoors.
Wide Application Range: Indoor backbone wiring, interconnection, patch cords and equipment links.
Meets Industry Standards: Meets YD/T1258.2-2009 and IEC standards.
Available with Various Fiber Types and Count: Can accommodate single-mode fibers G.652D, G.657, G.655, multimode fibers, and available in 1, 2, 4, 8, 12 and 24 cores.

Parameter	Specification
Model Type	0.9mm GJFJV Tight Buffer Fiber Optic Cable
Fiber Type	Single-mode (G.652D, G.657, G.655), Multi-mode
Fiber Count	1, 2, 4, 8, 12, 24 cores
Fiber Diameter	0.9 mm (tight buffered fiber)
Strength Member	Aramid yarn
Outer Jacket Material	LSZH (Low Smoke Zero Halogen) or PVC
Outer Jacket Color	Typically Yellow (single-mode), Orange (multi-mode) or customized
Cable Diameter	Approx. 5.0 mm to 6.8 mm (depending on fiber count)
Tensile Strength	Long-term: 200-300 N; Short-term: up to 600 N
Operating Temperature Range	-20°C to +70°C
Storage Temperature Range	-40°C to +85°C
Attenuation (Single-mode)	≤0.34 dB/km at 1310 nm; ≤0.20 dB/km at 1550 nm
Minimum Bending Radius	Installation: 20× cable diameter; Operation: 10× cable diameter
Flame Retardant Standard	Complies with IEC 60332-1, YD/T1258.2-2009
Smoke Emission	Low smoke emission (LSZH jacket)
Moisture Resistance	Outer jacket resists moisture and corrosion
Application	Indoor backbone wiring, patch cords, pigtails, equipment interconnection
Standards Compliance	YD/T1258.2-2009, IEC, UL (optional depending on jacket)

Additional Specifications

Outsheath Diameter (mm)	Tight Buffer Diameter (mm)	Weight (kg/km)	Minimum Allowable Tensile Strength (N)	Minimum Allowable Crush Load (N/100mm)	Minimum Bending Radius (mm)	Storage Temperature (°C)
1.6	0.6	2.8	Short term: 150; Long term: 80	Short term: 500; Long term: 100	Short term: 20D; Long term: 10D	40
1.8	0.6	3.0
2.0	0.9	4.25
2.4	0.9	5.0
2.8	0.9	6.6
3.0	0.9	7.0
